Item No.
U411

Adjusting the scanner automatically

Description
Uses a specified original and automatically adjusts the following items in the scanner and the DP
scanning sections.
Purpose
To perform automatic adjustment of various items in the scanner and the DP scanning sections.
Perform adjustments using a new test chart (chart 1) when replacing ISC PWB, LED lamp PWB,
ISU, CIS and/or DP main PWB.
Method
1. Press the start key.
2. Select the item.
Display
Table (Chart1)
DP FaceUp
(Chart1)
DP FaceDown
(Chart1)
Table (Chart2)
DP FaceUp
(Chart2)
DP FaceDown
(Chart2)
Target
DP Auto Adj
Method: [Table (Chart1)]
To automatically enter the target value
* : Select this option for normal use.
1. Set a specified original (P/N: 7505000005) on the platen.
2. Enter maintenance item U411.
3. Select [Target].
4. Select [Auto] and press the start key.
5. Select [Table (Chart1)].
6. Select the item.
* : Select All for normal use.
Description
Description
Automatic adjustment in the scanner sec-
tion (chart 1)
Do not use.
Automatic adjustment in the DP scanning
section (first side) (chart 1)
Automatic adjustment in the DP scanning
section (second side) (chart 1)
Automatic adjustment in the scanner sec-
tion (chart 2)
Automatic adjustment in the DP scanning
section (first side) (chart 2)
Automatic adjustment in the DP scanning
section (second side) (chart 2)
Set-up for obtaining the target value
Automatic adjustment of automatic docu-
ment processor using the chart printed
from the machine
1-3-134
2NP-2
Original to be used
for adjustment (P/N)
7505000005
7505000005
7505000005
302FZ56990
302AC68243
302AC68243/
303JX57010/
303JX57020
-
-
