Hdd Formatting; Firmware Update - Kyocera TASKalfa 2551ci Service Manual

Item No.
U024

HDD formatting

Description
Initializes the hard disk.
Purpose
To initialize the hard disk when replacing the hard disk after shipping.
Caution
In addition, the following settings are also initialized by initializing the hard disk.
System menu (user login administration, job accounting, address book, one-touch keys and doc-
ument box etc.), shortcuts and panel programs
When fully formatted, the following pre-installed software are removed.
Option language, PDF1.7 resource, FMU, weekly timer, color table
Method
1. Press the start key.
2. Select the item.
Full
Data
3. Press [Execute].
4. Press the start key to initialize the hard disk.
5. Turn the main power switch off and on. Allow more than 5 seconds between Off and On.
U025 Firmware Update(Security)
Description
Used to execute FW-Update from the USB flash device while Very High is selected in the Secu-
rity Level settings under the System Menu.
Purpose
Firmware upgrading is initiated by a service person to conduct U025 while a USB flash device is
inserted.
Method
1. Press the start key.
2. Press [Execute].
3. Firmware upgrading will begin when power is toggled off and on after the message to urge
power toggling is displayed.
4. After the firmware upgrade is completed normally, "FW-UPDATE Completed" will be dis-
played with the firmware version.
* : This is not executable when a USB has not been installed.
Display
Full format
Data format (the application software are retained)
Description
Description
1-3-33
2NP
