Item No.

Displaying fuser heater temperature

U199
Description
Displays the detected fuser temperature.
Purpose
To check the fuser temperature.
Method
1. Press the start key. The current setting is displayed.
Fix Press
Fix Edge
Fix Center
Completion
Press the stop key. The screen for selecting a maintenance mode No. is displayed.
U200

Turning all LEDs on

Description
Turns all the LEDs on the operation panel on.
Purpose
To check if all the LEDs on the operation panel light.
Method
1. Press the start key.
2. Select [Execute].
3. Press the start key.All the LEDs on the operation panel light.
4. Press the stop key. The LEDs turns off.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
Display
Press roller center temperature (°C)
Heat roller edge temperature (°C)
Heat roller center temperature (°C)
Description
Description
1-3-84
2NP
