Item No.
U065

Adjusting the scanner magnification

Description
Adjusts the magnification of the original scanning.
Purpose
Make the adjustment if the magnification in the main scanning direction is incorrect.
Make the adjustment if the magnification in the auxiliary scanning direction is incorrect.
Caution
Adjust the magnification of the scanner in the following order.
U065
main scan-
ning direction
Method
1. Press the start key.
2. Press the system menu key.
3. Place an original and press the start key to make a test copy.
4. Press the system menu key.
5. Select the item to be adjusted.
Display
Main Scan
Sub Scan
Adjustment: [Main Scan]
1. Change the setting value using the +/- keys or numeric keys.
For copy example 1, increase the value. For copy example 2, decrease the value.
2. Press the start key. The value is set.
Description
U065
auxiliary scan-
ning direction
Description
Scanner magnification in the
main scanning direction
Scanner magnification in the
auxiliary scanning direction
Original
Figure 1-3-7
1-3-44
Setting
range
-75 to 75
-125 to 125 0
Copy
Copy
example 2
example 1
Initial Change in
setting value per step
0 0.02 %
0.02 %
