Item No.
U469

Adjusting the color registration

Description
Performs the color registration correction.
Purpose
To perform when replacing the maintenance kit or laser scanner unit.
Method
* : Be sure to perform U464 Calib before performing this mode.
1. Press the start key.
2. Select the item.
Display
Auto
Manual
Method: [Auto]
1. Select [Print].
2. Press the start key. A chart for adjustment is outputted.
3. Set the output chart for adjustment as the original.
4. Select [Execute].
5. Press the start key. Color registration correction starts.
6. When normally completed, [OK] is displayed.
If a problem occurs during auto adjustment, error code is displayed.
Description
Executing the auto color registration correction
Executing the manual color registration correction
Chart for adjustment
Figure 1-3-44
1-3-153
Description
