Checking The Operation Of The Clutches/Solenoids - Kyocera TASKalfa 2551ci Service Manual

Item No.
U032 Checking the operation of the clutches
Description
Turns each clutch on.
Purpose
To check the operation of each clutch.
Method
1. Press the start key.
2. Select the clutch to be operated.
3. Press the start key. The operation starts.
Feed
Feed2
Regist
Duplex
Middle
DLP
Motor
4. Press the stop key.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
U033 Checking the operation of the solenoids
Description
Turns each solenoid on.
Purpose
To check the operation of each solenoid.
Method
1. Press the start key.
2. Select the solenoid to be operated.
3. Press the start key. The operation starts.
MPT
Eject
4. To stop operation, press the stop key.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
Display
Paper feed clutch 1 (PFCL1) is turned on
Paper feed clutch 2 (PFCL2) is turned on
Registration clutch (RCL) is turned on
Duplex clutch (DUCL) is turned on
Middle clutch (MCL) is turned on
Developer stop clutch (DEVSCL) is turned on
Motor ON
Display
MP solenoid (MPSOL) is turned on
Feedshift solenoid (FSSOL) is turned on
Description
Description
Description
1-3-36
2NP
