Item No.
U053

Setting the adjustment of the motor speed

Description
Performs fine adjustment of the speeds of the motors.
Purpose
Basically, the setting need not be changed. Modify settings by interlock setting only if faulty
images occur.
Method
1. Press the start key.
2. Select the item. The screen for executing each item is displayed.
Display
Full
Half
3/4
Setting
1. Select the item to be adjusted.
Display
Feed
Exit
Drum(CMY)
Drum(K)
DLP(CMY)
DLP(K)
Fixing
Feed2
2. Change the setting value using the +/- keys or numeric keys.
3. Press the start key. The value is set.
Completion
Press the stop key. The indication for selecting a maintenance item No. appears.
Description
Speed correction value setting at full velocity
Speed correction value setting at half velocity
Speed correction value setting at 3/4 velocity
Description
Conveying motor 1 (CM1) speed adjustment
Eject motor (EM) speed adjustment
Drum motor (DRM-YCM) speed adjustment
Drum motor (DRM-K) speed adjustment
DLP motor (DEVM-YCM) speed adjustment
DLP motor (DEVM-K) speed adjustment
Fixing motor(FUM) speed adjustment
Conveying motor 2 (CM2) speed adjustment
1-3-42
Description
2NP
Setting
range
-50 to 50
-40 to 40
-50 to 50
-50 to 50
-50 to 50
-50 to 50
-50 to 50
-50 to 50
