(2) Machine (rear side)
29
30
27
26
28
19. Rear cover
20. Rear cover lever
21. IF cover
22. Memory cover
23. Power cord cover
24. Paper conveying unit
25. Power cord connector
22
23
Figure 1-1-2
26. USB memory slot
27. USB interface connector
28. Network interface connector
29. LINE connector
30. TEL connector
1-1-7
24
21
25
2PZ
19
20
