Printing the card parameters (LD 20)
LD 20 – Print DAC parameters.
Prompt Response
REQ: PRT
LTN
LUU
TYPE: R232
R422
DAC
TN l s c u
By responding R232, R422, or DAC to the TYPE prompt in LD 20, you can
print out the configured parameters for each port, or the entire DAC. This is
useful to determine if any parameters have been altered during keyboard or
Hayes dialing modify procedures.
Description
Print data, TN, or unit information for the unit specified
Print information for the RS-232-C, RS-422 ports, or the
whole DAC
Print information for this TN, where l = loop, s = shelf,
c = card, u = unit. Uploaded parameters can only be
printed when a specific TN is listed.
The operation parameter printout for an RS-232 or RS-422 port is similar to
the following, depending on the configuration.
Table 172
Print out example (Part 1 of 2)
PAR
DTR
HOT
AUT
Note: The Upload parameters are printed only when a single TN is
specified.
NT7D16 Data Access card
DBASE
R-232 or R-422
SPAC
ON
OFF
ON
Circuit Card
Page 521 of 906
UPLOAD
R-232 or R-422
SPAC
ON
OFF
O
