Software description

Hardware description

NTRB21 TMDI card

Architecture

Signaling interface
Interconnection
Changes from the NTAK09 are required for the new trunk card and License
parameters are n service change and maintenance overlays. There is a change
to CardLAN to introduce a new CardLAN ID. The download of PSDL data
is also changed to handle a 32 bit download as well as existing 16 bit.
The NTRB21 TMDI card provides 1.5 MBits Digital Trunk Interface or
Primary Rate Interface functionality. It also has a built-in downloadable
D-channel.
The NTRB21 can be used with the NTAK09 DTI/PRI card (with the
NTBK51 downloadable D-channel daughterboard).
Figure 178 on page 832
The signaling interface performs an 8 Kbps signaling for all 24 channels and
interfaces directly to the DS-30X link. Messages transmitted in both
directions are three bytes long.
The interconnection to the carrier is by NTBK04, a 1.5 Mb 20 ft. carrier cable.
The NT8D97AX, a fifty-foot extension cable, is also available.
NTRB21 DTI/PRI/DCH TMDI card
shows a faceplate of the NTRB21 TMDI card.
Circuit Card
Page 831 of 906
Description and Installation
