Page 512 of 906
Figure 100
Patch panel layout
50-pin connector
553-3001-211 Standard 3.00
NT7D16 Data Access card
DB25
Note: Use an octopus cable that follows the pinout of the DAC, such as
QCAD318A (female) and QCAD319A (male), in conjunction with a
50-pin female-to-female gender converter.
August 2005
DB25
50-pin connector
553-5021
