NTDK20 Small System
Controller card

Contents

Introduction

This section contains information on the following topics:
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
100BaseT IP daughterboards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PC card interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Security device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SDI ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Conferencing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
MG 1000S/Expansion card slot assignment . . . . . . . . . . . . . . . . . . . . .
This chapter introduces the NTDK20GA Small System Controller (SSC)
Card used in the Call Server, MG 1000S, and Media Gateway 1000B
(MG 1000B). It controls call processing, stores system and customer data,
and provides various 100BaseT IP interfaces.
You can install this card in slots 1 through 4 in the MG 1000S or slots 7
through 10 in the MG 1000S Expansion
The NTDK20FA SSC card is the minimum vintage of SSC that can be used
in the Call Server and MG 1000S. See Figure 170 on page
Circuit Card Description and Installation
Page 811 of 906
811
814
815
818
819
820
820
821
813.
