13.3.1.4 Concluding steps

"Installing the front panel module" on page 239
Ê
"Reassembling" on page 52
Ê
"Connecting the server to the mains" on page 55
Ê
"Switching on the server" on page 57
Ê

13.3.2 Removing the front VGA board

Upgrade and Repair Unit
(URU)
Tools: Phillips PH1 / (+) No. 1 screw driver

13.3.2.1 Preliminary steps

"Shutting down the server" on page 45
Ê
"Disconnecting the server from the mains" on page 46
Ê
"Getting access to the component" on page 47
Ê
"Removing the front panel module" on page 237
Ê
RX1330 M1
Upgrade and Maintenance Manual
Hardware: 10 minutes
Front panel
243
