The LEDs have the following meaning:
LED
A - CSS
(Customer Self
Service)
B - GEL
(Global Error
LED)
C - Identification blue on
D - Memory
E - AUX power
F - System fan
G - PCI card
H - iRMC
RX1330 M1
Indicator
Meaning
off
no error (CSS component)
orange on
indicates a prefailure (CSS component)
orange flashing indicates a failure (CSS component)
off
no error (non CSS component)
orange on
indicates a prefailure (non CSS
component)
orange flashing indicates a failure of a non CSS
component.
Reasons for a failure may be:
– over temperature measured by one of
– sensor is defective
– CPU error
– software detected an error
server has been highlighted using iRMC
web frontend, ServerView Operations
Manager or the ID button on the front
panel for easy identification
blue flashing
local monitor off
off
memory module running
orange on
memory module failure
off
orange on
voltages okay
off
system fan running
orange on
system fan failure
off
PCI card okay
orange on
PCI card failure (PCI card installed on riser
card)
off
iRMC S4 inactive
green flashing
iRMC S4 okay
Upgrade and Maintenance Manual
the sensors
Appendix
303
