Lucent Technologies MERLIN LEGEND Release 7.0 System Planning Manual page 355

MERLIN LEGEND Communications System Release 7.0
System Planning 555-670-112
D T1/PRI Planner
8. On page 2, complete one check box for each 100D module by transferring
the options information for each module from the corresponding check box
on Form 3b (page 1):
a.
b.
c.
d.
e.
9. To ensure that the synchronization integrity of the DS1 network
this communications system and its far-end connections
prepare the DS1 Planning Map on page 4 for review by SDSC. Describe
the entire network of DS1 facilities by summarizing the following for each
100D module:
a.
b.
c.
d.
Service Ordered or Planned (Type of Service)
Frame Format
Switch Type
Line Coding (Suppression)
Line Signaling Mode
f. Synchronization Timing (Clock Synchronization: Source)
Fill in the control unit slot number or numbers of the 100D modules
connected to the CSU or CSUs.
Write the approximate number of cable feet between each module
and its CSU or far-end connection (refer to the Line Compensation
entry on Form 3b, Page 1).
For the model number or numbers of the CSU or CSUs, do one of
the following:
If the CSU is the ACCULINK 3150, check the check box for
the ACCULINK 3150.
If the CSU is not the ACCULINK 3150, check the Other check
box and write the manufacturer's name and model number in
the space provided at the bottom of the page.
If no CSU is needed, check the None check box.
In the connection block or blocks, describe the DS1's far-end
connection by doing one of the following:
If connected to the telephone company central office, check
the central office check box.
If connected to another communications system, check the
PBX check box.
If connected to the PRI network, check the PRI check box.
If the facility's type of service is T1, check the type or types of
emulated trunks. Also, check the Services check box if the
facility includes services such as MultiQuest with DNIS.
Issue 1
April 1999
D-3
both
is protected,
