3 Lines/Trunks
Selecting Line/Trunk Options
NOTES:
Planning Form Instructions
1. See
in the numbering plan you have selected. Before you begin planning
remote access, to assure that TTRs are available, check the Control Unit
Diagram on Form 1 to verify that one or more of the following types of
modules are present: 400 (LS), 400 GS/LS/TTR, 008 OPT, 800 DID
(Hybrid/PBX mode only), 800 GS/LS-ID, 012 (T/R), or 016 (T/R) module;
or, in Release 7.0 and later systems, the 412 LS-ID-ETR or 016 ETR
module.
2. Under the DID and Private Network Tie Trunks heading at the top of Form
3a, Incoming Trunks: Remote Access, do either of the following:
Under the Automatic Callback heading at the top of Form 3a, check either
3.
of the following:
If you want to allow remote access on DID trunks, the routing digits
supplied by the central office must match the factory-set remote access
code (889) or the remote access code assigned to the system in the
following procedure.
Trunks programmed for both remote access and Group Calling will
receive remote access treatment only.
Remote access callers may not log in to a calling group but may call the
calling group by dialing the group access number.
Private network calls may use the Remote Access feature if the remote
access code is included in the non-local dial plan.
''Numbering the System''
To keep the factory-set access code, check Remote Access Code:
889 and proceed to Step 3.
To change the factory-set access code:
— Check Renumber to and write the new number on the line
provided.
— On Form 2d, System Numbering: Special Renumbers, write
the new number in the Renumber to column of the Remote
Access Code section at the bottom of the form. Proceed to
Step 3.
If you do not want remote callers to use the Automatic Callback
feature, check Disable (factory setting).
To allow remote callers to use this feature, check Enable.
NOTE:
Private network calls to Remote Access cannot use the
Automatic Callback feature.
in Chapter 2. Review the numbers available
Issue 1
April 1999
3-19
