2 Control Unit Configuration
Numbering the System
Jack for Primary Operator Position
The factory setting for the primary operator position is the lowest extension jack
on the first MLX or analog multiline telephone module. You cannot change the
factory setting for the primary operator position.
The primary operator position uses two types of operator consoles:
If the system includes QCCs, the primary operator position must be a QCC.
Planning Form Instructions
Mark jack assignments on Form 2a:
1. Do either of the following:
2. Obtain the logical ID of the extension jack for the system programming
console by referring to the System Operating Conditions heading, Form 1
(page 2).
3. Identify the logical ID for the system programming console by writing
beside the appropriate logical ID in the Log. ID column of Form 2a.
4. Write either the name of the person who will program the system or the
location of the system programming console in the Person, Location, or
Function column. Then proceed to Step 5.
Do either of the following:
5.
6. To indicate the primary QCC operator position:
a.
b.
c.
Direct-Line Console (DLC). Can be assigned to either a digital or
an analog extension jack.
Queued Call Console (QCC). Can be assigned only to a digital
extension jack, and the MLX-20L is the only telephone that can be
used as a QCC.
If the system uses a system programming console, proceed to
Step 2.
If the system does not use a system programming console, skip to
Step 5.
To indicate the primary QCC operator position for a system with one
or more QCCs, proceed to Step 6.
To indicate the primary DLC operator position for a system with one
or more DLCs, skip to Step 7.
Locate the first extension jack showing a D (digital) jack type and
write beside the preprinted logical ID number.
Write the name or location of the primary QCC operator in the
Person, Location, or Function column.
On Form 1 (page 2), write the extension of the QCC under System
Consoles.
