MERLIN LEGEND Communications System Release 7.0
System Planning 555-670-112
3
Lines/Trunks
Assigning Telephone Buttons

Telephones in Key and Behind Switch Mode

The line buttons you assign to the telephones, or to the adjuncts connected
through an MLX telephone using an MFM, are the following:
Intercom Ring (ICOM Ring) button
Intercom Voice (ICOM Voice) button
Intercom Originate Only (ICOM Orig Only) button
Loudspeaker Paging button
Personal line button (Key mode only)
Prime line button (Behind Switch mode only)
NOTE:
In Behind Switch operating mode, the system automatically assigns two
prime lines to each port on an MLX module — one for the MLX telephone
and one for the device connected to the Multi-Function Module (MFM). If an
MFM is not connected to an MLX telephone or the MLX port is not used, the
prime line for the MFM can be removed. The prime line can then be
assigned to other users.
Factory Assignments
The system automatically assigns certain kinds of line buttons depending on the
type of equipment and the mode of operation:
In Key mode, the system assigns an ICOM Ring button and an ICOM Voice
button; the first eight outside lines connected to the control unit are
assigned to each nonoperator multiline telephone, beginning with Button 3.
In the Behind Switch mode, the system assigns an ICOM Voice button, an
ICOM Ring button, and one prime line button (Button 3) to every
nonoperator multiline telephone.
For either mode, the line/trunk assignment is the same for analog multiline,
MLX, ETR, and MLS telephones, except for the MLS-6 telephone.
The factory-setting button assignments for an MLS 12/12-D telephone are
the same for the TransTalk and Business Cordless 905 telephones.
Figure 3-11
Figure 3-12
telephones.
ETR telephones in Key mode.
set assignments for MLS telephones in Key mode. For factory-set assignments in
Behind Switch mode for ETR and MLS telephones, see
Figure
3-26.
illustrates the factory-set button assignments for MLX telephones.
illustrates the factory-set button assignments for analog multiline
Figure 3-13
through
Figure 3-16
3
3
Figure 3-15
show the factory-set assignments for
through
Figure 3-19
Issue 1
April 1999
show the factory-
Figure 3-20
through
3-61
