MERLIN LEGEND Communications System Release 7.0
System Planning 555-670-112
2 Control Unit Configuration
Numbering the System
1. On the Control Unit Diagram on Form 1, determine which extension jacks
can be used as operator positions by circling the first and fifth extension
jacks on digital or analog modules until you have reached the maximum
number of eight positions. For Release 7.0 and later systems, the 016 MLX
module has potential operator positions on the first, fifth, ninth, and
thirteenth extension jacks.
2. On Form 2a, mark the extension jacks to be used as additional operator
positions.
3. Do either of the following:
4. For each additional QCC:
a.
b.
c.
5. For each additional DLC:
a.
b.
c.
6. If the system includes any Call Management Systems, write
Person, Location, or Function column next to the logical ID for the two DLC
positions assigned for each CMS.
Proceed to the next section,
Extension Jack Pairs for Analog Telephones
Use these instructions only if the system has analog multiline telephones.
Otherwise, skip to the next section,
MLX telephones can use the Voice Announce feature or simultaneous voice and
data without requiring a second extension jack.
If the system has additional QCCs, proceed to Step 4.
If the system has additional DLCs, skip to Step 5.
Write next to the preprinted logical ID for each additional QCC
position. Be sure to assign QCCs to only the first and fifth extension
jacks on each digital module.
Write the name or location of each additional QCC operator in the
Person, Location, or Function column.
On Form 1 (page 2), write the extension number of each additional
QCC in the System Consoles box.
Write next to the preprinted logical ID for each additional DLC
position, including DLC positions used for calling group supervisors
and for the optional CMSs. Be sure to assign DLCs to only the first
and fifth extension jacks on each digital or analog module.
Write the name or location of each additional DLC operator in the
Person, Location, or Function column.
On Form 1 (page 2), write the extension number of each additional
DLC in the System Consoles box.
''Extension Jack Pairs for Analog
2
''Jacks for MLX Telephones."
Issue 1
April 1999
2-25
in the
Telephones."
