MERLIN LEGEND Communications System Release 7.0
System Planning 555-670-112
6 Modifications

Adding to the System

3. Before revising the forms, analyze and document the changes planned.
For example:
4. Review security information in
Information," for details on how to minimize the risk of toll fraud.
Adding to the System
Adding to the system is defined as increasing its capacity or capability. This
increase may mean adding more or different kinds of lines/trunks, connecting
auxiliary equipment, or installing more telephones, consoles, or T/R equipment.
Forms Needed
1, System Planning
2a, System Numbering: Extension Jacks
2c, System Numbering: Line/Trunk Jacks
Planning Form Instructions
1. Determine the specific type of line/trunk, auxiliary equipment, or
telephones to be added. Then determine the type of line/trunk and/or
extension module needed to support the additional equipment. Consider
the following as you choose the modules:
If adding extensions to the system, revise the floor plan to show the
location of the new telephones and the kind of equipment to be
used.
If activating a feature such as System Speed Dial, survey
employees to identify the numbers that should be programmed into
the speed dial file.
DS1 connectivity configured for T1 operation provides 24 channels.
T1-Tie trunks may be configured to use Switched 56 service.
NI-1 BRI service provides 16 channels per 800 NI-BRI module.
If you are planning for Remote Access, at least one module with
touch-tone receivers (TTRs) must be installed.
If analog multiline telephones require either voice and data or Voice
Announce when the telephone is busy, two consecutive telephone
jacks are required.
If you are connecting T/R equipment to the 008 (ATL), 408 (LS-ATL),
or 408 GS/LS modules, a GPA is required.
If you are connecting T/R equipment to the 016 ETR or 412 LS-ID-
ETR module (Release 7.0 and later systems), you must program the
port for tip/ring operation.
Appendix A, ''Customer Support
6
Issue 1
April 1999
