3 Lines/Trunks
Selecting Line/Trunk Options
5. To select dial mode: under the Inmode heading, check either the Touch-
Tone column or Rotary column (factory setting) for each incoming-only and
each two-way tie trunk. Use Touch-Tone for private networks.
6. To indicate whether the system provides a dial tone for people calling in on
a tie trunk, check either of the following for each tie trunk under the Dial
Tone heading:
7. For Answer Supv. Time, do either of the following:
Under the Disconnect Time heading, do either of the following:
8.
Proceed to the next section,
NOTE:
When connecting a MERLIN LEGEND switch to a DEFINITY
switch, use the Type 5 signaling type.
NOTES:
If you have checked the Incoming or two-way column for a
tie-trunk's direction and Immediate for its incoming signaling type,
you cannot use the Touch-Tone setting for Inmode.
Touch-Tone outmode can be used with Outtype Immediate
trunks, but Touch-Tone inmode cannot be used with Intype
Immediate Trunks.
Under the Outmode heading, check either the Touch-Tone
column or the Rotary column (factory setting) for each outgoing-
only and each two-way tie trunk.
If the system provides a dial tone, check Remote (factory setting).
Use this setting for private networks.
If the system does not provide a dial tone, check Local.
To keep the factory setting, check the 300 column. (Use this setting
for private networks.)
To change to a new value, write the new value (20 to 4800 ms) in
the Other column. (Use 20-ms increments.)
To keep the factory setting, check the 300 column. (Use this setting
for private networks.)
To change to a new value, write the new value (140 to 2400 ms) in
the Other column. (Use 10-ms increments.)
''DID Trunks (Hybrid/PBX Mode
Issue 1
April 1999
3-43
Only)."
