3 Lines/Trunks
Selecting Line/Trunk Options
T1 Service
T1 service allows the emulation of different analog lines. You can also order
services, such as Megacom 800, over the channels. The capacity, however, is
limited to voice calls and data calls using a modem. In addition, beginning with
Release 4.0 of the MERLIN LEGEND Communications System, T1 supports
ACCUNET Switched Digital Service (or other circuit-switched data service) at
56-kbps when the T1 channel or T1-Tie trunk is configured as T1 Switched 56.
Release 6.0 and later systems allow T1 service to provide tandem PRI service in
a private network.
The planning form instructions below apply to both T1 and T1 Switched 56 service
except where noted. If you are configuring channels for T1 Switched 56 service,
complete these instructions then proceed to the
section that immediately follows. If configuring T1-Tie trunks for T1 Switched 56
service, proceed to the
you are planning to use T1 service as PRI trunks in a private network, check the
PRI box under Type of Service on Form 3b (page 1). See the Network Reference
for more information regarding configuration for use in a private network.
Planning Form Instructions
Fill in the following on Form 3b (page 1), Incoming Trunks: DS1 Connectivity
(100D Module), for each 100D module in the system:
1. In the Module Slot No. space, write the number of the control unit slot that
contains the module (see the Control Unit Diagram on Form 1).
2. Under Type of Service, check T1 (the factory-setting).
''Tie Trunks''
NOTE:
If more than one 100D module is used, complete the first box,
Module 1, to show the options assigned to the 100D module in the
lowest number control unit slot. Use the second box for the second
lowest-numbered slot, and the last box for the highest-numbered
slot.
NOTES:
For T1 or T1 Switched 56 service, the T1 box must be checked
on the form. (If you leave this blank, and T1 is not specified
during programming, the 100D module will not be programmed.)
Steps 3, 4, 5, and 6 must match the service provider settings.
Check with the provider if necessary. See
Company Information," in
3
''T1 Switched 56 – Network''
section after completing these instructions. If
Chapter 1, for more information.
