3 Lines/Trunks

Assigning Lines/Trunks

Assigning Lines/Trunks
This section contains instructions for assigning lines/trunks to telephones and
Direct-Line Consoles.
NOTE:
To assign lines/trunks to data-only stations, follow the instructions in
Chapter
Forms Needed
2a, System Numbering: Extension Jacks
2b, System Numbering: Digital Adjuncts
Use the following forms as appropriate for telephones and consoles in the
system. Make one copy of the appropriate form for each extension.
Planning Form Instructions
1. On page 1 of Forms 4b, 4d, 4h, 4j, 5a, and 5b, transfer the following user
information from Form 2a, System Numbering: Extension Jacks to each
copy of each of these telephone forms:
a.
b.
c.
5, ''Data Communications."
— 4b, Analog Multiline Telephone
— 4d, MLX Telephone
— 4e, MFM Adjunct: MLX Telephone
— 4f, Tip/Ring Equipment
— 4h, ETR Telephone
— 4j, MLS Telephone
— 5a, Direct-Line Console (DLC): Analog
— 5b, Direct-Line Console (DLC): Digital
— 5c, MFM Adjunct: DLC
Write the logical ID in the Logical ID space.
Write the extension number in the Extension No. space.
Write the name of the person or the location of the equipment in the
Person or Location space.
