5 Data Communications
Assigning Lines/Trunks to Data and Video Stations
To assign lines/trunks to data stations, you decide on the types of line buttons that
are assigned to the data communications equipment at each data station. The
data stations are:
Analog voice and modem data stations and MLX voice and modem data
stations
MLX voice and ISDN terminal adapter data stations, including telephones
Modem data-only stations
ISDN terminal adapter data-only stations
Digital data/video stations
The system treats each data station, except for analog voice and modem data
stations, as an extension with a 34-button telephone.
When you choose the mode of operation (Key, Behind Switch, or Hybrid/PBX),
Intercom (ICOM) or System Access (SA) buttons are assigned automatically to
every extension connected to the control unit. However, you can customize the
system by changing the factory-set assignments and reassigning line buttons.
The number and types of buttons assigned depends on the mode chosen and the
type of extension jack you are using.
NOTE:
Trunks cannot be independently assigned to analog voice and modem data
stations. The line/trunk assignment for the telephone also includes the
modem extension; therefore, these instructions are not used for these types
of data stations.
Forms Needed
Data Form 1a, Modem Data Stations
Data Form 1b, Data Stations
Form 4e, MFM Adjunct: MLX Telephone
Form 5c, MFM Adjunct: DLC
Planning Form Instructions
You should have already filled out preliminary information on Forms 4e and 5c
when you planned voice communications. The lines/trunks for MLX telephones
have already been assigned.
