MERLIN LEGEND Communications System Release 7.0
System Planning 555-670-112
5 Data Communications
Assigning Extension Jacks
Planning Form Instructions
Record the extension jack assignments for access to a workstation on a LAN on
Form 2a, System Numbering: Extension Jacks.
1. For each digital extension jack used to connect an ISDN terminal adapter:
a.
b.
2. For each tip/ring extension jack you plan to use to connect a modem:
a.
b.

Video Systems

Video systems may connect to an MLX port on the MERLIN LEGEND System
either directly through a BRI interface, or by way of a v.35 interface and an ISDN
terminal adapter.
Assign each video system that is connected directly to the MLX port, or connected
to an ISDN terminal adapter that supports 2B Data, to one digital jack configured
as a 2B Data port on an 008 MLX, 408 GS/LS-MLX, 408 GS/LS-ID-MLX, or 016
MLX (Release 7.0 and later systems) module.
Assign each video system that is connected to an MLX port by way of an ISDN
terminal adapter that does not support 2B Data to two separate digital jacks
configured as 1B Data ports on an 008 MLX, 408 GS/LS-MLX, 408 GS/LS-ID-
MLX, or 016 MLX (Release 7.0 and later systems) module.
Planning Form Instructions
Record the extension jack assignments for video systems on Form 2a, System
Numbering: Extension Jacks.
1. In the Jack Type column, make sure there is a
each digital extension.
2. In the Person, Location, or Function column, enter the type of equipment
connected.
In the Jack Type column, make sure there is a
for each digital extension.
In the Person Location, or Function column, write
In the Jack Type column, make sure there is a
for each tip/ring extension jack used to connect a modem.
In the Person, Location or Function column, write
next to the number
next to the number
5
next to the number for
Issue 1
April 1999
5-24
