2 Control Unit Configuration
Numbering the System
Jacks for Tip/Ring Equipment and Applications
Use these instructions only if the system includes 012 (T/R), 016 (T/R), 016 ETR,
008 OPT, or 412 LS-ID-ETR modules. Otherwise, skip to the section, ''Labels."
Ports 1-8 on the 412 LS-ID-ETR module are ETR ports only; the remaining 4 ports
support tip/ring or ETR functionality, but not both simultaneously.
On the 016 ETR module, the first 10 ports are ETR ports only; ports 11-16 support
tip/ring or ETR functionality, but not both simultaneously.
Assign the tip/ring jacks on the 012 (T/R), 016 (T/R), 016 ETR, 008 OPT, or 412
LS-ID-ETR modules to any tip/ring equipment such as single-line telephones, fax
machines, analog modems, or Group Calling Delay Announcement Devices. The
hardware design of the 008 OPT module includes an interface for off-premises
telephones, which supplies increased gain levels and protection.
If assigning tip/ring jacks on an 016 (T/R) module, the Ringing Frequency may be
set to either 20-Hz (Type A) or 25-Hz (Type E). The Ringing Frequency is
programmable on each 016 (T/R) module and affects all ports on that module.
Several optional applications, if used with the system, require tip/ring jacks. These
jacks are found on an 012 (T/R) or 016 (T/R) module, or on ports 9–12 of a 412
LS-ID-ETR module or ports 11–16 of a 016 ETR module when these ports are
programmed for tip/ring operation. The optional applications include:
Enhanced Service Center
Messaging 2000
Intuity AUDIX
Lucent Technologies Attendant
AUDIX Voice Power – Integrated Solution II (IS II)
Integrated Voice Power Automated Attendant – IS II
Do not use the 008 OPT module for these applications.
The system can accept up to eight application ports (extension jacks for
applications) using the 012 (T/R) module. All 16 ports on the 016 (T/R) module
may be used for applications.
In Release 7.0 and later systems, you can select Rotary Dial Enable for each tip/
ring port. When you enable rotary dialing for a port, the port accepts both rotary
dialing and touch-tone signals. If you leave the port on the factory setting of touch-
tone only, no rotary dialing signals are accepted by that port. Activate Rotary Dial
Enable when you connect a rotary-dial device to the communications system.
