Set Number of Symbols
Number of Symbols determines the number of symbols to which output formatting will apply.
Output Phrase
Output Phrase refers to the user-defined Preamble, selected symbols, and Postamble
sequence in the read cycle result.
Enter Postamble characters by
double-clicking in the text field and
then using the Postamble calculator.
QX Hawk Industrial Imager User's Manual
Use the Set Number of Symbols spin box to
determine the number of symbols to be included
in the output phrase.
Check the
Parse boxes
beneath the
symbols to
be formatted.
Enter Postamble characters by
double-clicking in the text field and
then using the Postamble calculator.
Setup
4-29
