Request Checksum
Send a request to the imager for application code or DSP code checksums.
1. Click the Firmware tab.
2. Select App Code or DSP Code from the dropdown menu to the left of the Request
Checksum button.
3. Click the Request Checksum button to see the part number displayed in the text
field to the right.
Request Checksum by Serial Command
• When
<!>
(a request for all available firmware checksums) is sent, the imager returns:
<!a/APP_CHECKSUM><!d/DSP_CHECKSUM>
• When
<!a>
(a request for the application code checksum) is sent, the imager returns:
<!a/APP_CHECKSUM>
• When
<!d>
(a request for the DSP code checksum) is sent, the imager returns:
<!d/DSP_CHECKSUM>
QX Hawk Industrial Imager User's Manual
Utilities
7-19
