Symbol Quality Output 2
Symbol Quality Output 3
Output 1 Parameters
Output 2 Parameters
Output 3 Parameters
Matchcode
Matchcode
Master Symbol Database Size
New Master Pin
Master Symbol
Match Replace
Mismatch Replace
Diagnostics
Hours Since Reset (Read-only)
Service Message
User-Defined Name
Output Format
Format Extract
Format Insert
Format Assign
Output Format Status
Output Filter Configuration
Output Filter Enable
QX Hawk Industrial Imager User's Manual
<K801,Output on Symbol Contrast,Symbol Contrast Threshold,
Output on Print Growth,Print Growth Threshold,Output on Axial
Non-Uniformity,Axial Non-Uniformity Threshold,Output on
Unused ECC,Unused ECC Threshold>
<K802,Output on Symbol Contrast,Symbol Contrast Threshold,
Output on Print Growth,Print Growth Threshold,Output on Axial
Non-Uniformity,Axial Non-Uniformity Threshold,Output on
Unused ECC,Unused ECC Threshold>
<K810,output on,output state,pulse width,output mode>
<K811,output on,output state,pulse width,output mode>
<K812,output on,output state,pulse width,output mode>
<K223,matchcode type,sequential matching,match start position,
match length,wild card,sequence on no read,sequence on mismatch>
<K224,number of master symbols>
<K225,status>
<K231,index,master symbol data>
<K735,status,replacement string>
<K736,status,replacement string>
<K407> (returns: hours,minutes)
<K409,status,service message, threshold,resolution>
<K412,user-defined name>
<K740,output index,start location,length>
<K741,output index,length,hex string>
<K742,symbol number,status>
<K743,output format status>
<K744,filter number,symbology,length,wildcard,placeholder,
data,unused,database index>
<K745,number of filters>
Appendices
A-15
