Electrical
Power Requirement: 5-28VDC
Discrete I/O
Input 1 (Trigger/New Master): Optoisolated, 4.5–28V rated (13 mA at 24VDC); New Master is (–) to signal
ground
Outputs (1, 2, 3): Optoisolated, 1–28V rated (I
< 100 mA at 24VDC, current limited by user)
CE
Safety Certifications
CDRH, FCC, CE, CB, BDMI (compliant)
RoHS/WEEE Compliant
ISO Certification
ISO 9001 Certified
Issued by TüV USA
©2010 Microscan Systems, Inc.
All rights reserved. Specifications subject to change.
Product specifications are given for typical performance at 25°C (77°F) using grade A labels. Performance
characteristics may vary at high temperatures or other environmental extremes. Warranty–One year limited
warranty on parts and labor. Extended warranty available.
A-3
QX Hawk Industrial Imager User's Manual
