Master Database

Master Symbol Database Size

Master Symbol Database Size allows the user to select 1 to 10 master symbols for the
master symbol database.
Set Master Symbol
Database Size here.
Important: Since the total number of characters available for the master symbol database
is 3000, changes to the Master Symbol Database Size will re-allocate the number of
characters available for each master symbol and could cause existing master symbols to
be deleted (except master symbol # 1, unless it also exceeds the size limitation).
The table below specifies the maximum number of characters available to each symbol
according the number of master symbols defined, from 1 to 10.
Master Symbol
Number
# 1
# 2
# 3
# 4
# 5
# 6
# 7
# 8
# 9
# 10
7-12
Maximum
Characters
3000
1500
1000
750
600
500
428
375
333
300
