Firmware
Click the Utilities button and then the Firmware tab to
display the Firmware view.
Firmware Update
Firmware Update is used to download application code to the imager. Application code
versions are specific to the imager. Consult with a sales representative before downloading
application code. If needed, application code can be requested from Microscan.
To download application code:
1. First, be sure that the imager is connected to the host computer.
2. Apply power to the imager.
3. In the Firmware Update dropdown menu, select App Code. This will open a dialog
that allows the user to browse for the application code file.
4. Navigate to where the application code file is located on the host computer.
5. Allow approximately a minute for firmware to download.
As the application code begins to download, the imager will be silent, the LEDs will
flash intermittently, and a progress indicator at the bottom of the ESP window will
show when the download is complete.
Caution: Do not interrupt power or disconnect the host cable while download is in progress.
QX Hawk Industrial Imager User's Manual
Utilities
7-17
