Serial Commands
Configuration Database
Number of Active Indexes
Configuration Database
Load Current Setting
Request Database Index Setting <K255?,index>
Request All Database Settings <K255?>
Database Mode
Number of Active Indexes
Number of Active Indexes
Serial Cmd: <K252,number of active
Default: 0 (Disabled)
Options: 0 to 10
Number of Database Cycles
Serial Cmd: <K252,number of active
Default: 0 (Disabled)
Options: 0 to 255
A-34
<K252,number of active indexes,sort database>
<K255,index,shutter speed,gain,focal distance,sub-sampling,row
pointer,column pointer,row depth,column width,threshold mode,fixed
threshold value,processing mode,background color,narrow margins,
symbol type>
<K255–,index>
<K256,switch mode,frame count/time,image process looping, image
dimensions>
indexes,number of database cycles>
indexes,number of database cycles>
