Diagnostics

Click the App Mode button and then the Parameters button to display the
tree control tabs.
Then click the Diagnostics tab to display the Diagnostics tree control.
To open nested options,
single-click the +.
Note: Matchcode settings can also be sent to the imager from ESP's Terminal using
Microscan's K command format. Refer to the
QX Hawk Industrial Imager User's Manual
To change a setting, double-click
the setting and use the cursor to
scroll through the options.
Diagnostics
*
The indicates
that the setting
is the default.
section of Appendix
Parameters
E.
5-171
