Navigating in ESP

To change imager settings, or to access the Setup, Terminal, or Utilities views, click the
App Mode button.
To return to EZ Mode, click the EZ Mode button.
To make changes to configuration settings in the tree controls:
1. Left-click on the + to expand
menu items.
2. Double-click the desired
parameter and single-click
in the selection box to view
options.
3. Place the cursor in the
selection box, scroll down
to the desired setting, and
single-click the setting.
QX Hawk Industrial Imager User's Manual
4. Left-click again on the open screen to complete the
selection.
5. Right-click on the open screen and select Save to
Reader to implement the command in the imager.
The command can be sent without saving, or sent
and saved simultaneously.
Using ESP
X
The
indicates
that the
setting is
default.
2-15
