Test Read Rate
Step 9 — Test Read Rate
Read Rate indicates the number of successful decodes per second achieved by the imager.
Test Read Rate by ESP
1. Click the Test button to start the Read Rate test.
If a symbol has been successfully decoded, its data and related information will be
presented in the field below the image display window. While the symbol is being
decoded, the Read Rate LEDs will indicate the corresponding read rate percentage
on the top of the unit.
2. Click the Stop button to end the Read Rate test.
Note: Read rate can also be tested using the Read Rate interface in Utilities.
Test Read Rate by EZ Button
1. To start the Read Rate test, hold down the EZ Button about three seconds until you
hear three short beeps. The 20%, 40%, and 60% LEDs will illuminate.
While the symbol is being decoded, the Read Rate LEDs will indicate the corresponding
read rate percentage on the top of the unit.
2. To end the Read Rate test, press the EZ Button and quickly release.
Test Read Rate by Serial Command
You can also start a test with the
1-12
100%
80% These LEDs represent the
60% percentage of Good Reads
40% per images captured.
20%
<C> or <Cp> command and end it with the
QX Hawk Industrial Imager User's Manual
<J> command.
