Differences From Default - Microscan QX Hawk User Manual

Differences from Default

Differences from Default

Click the Utilities button and then the Differences tab to
display the Differences from Default view.
Clicking the Differences from Default button will cause ESP to check all stored configuration
settings and compare them to default settings. All settings that are different than default
will appear in the left column (shown below), and descriptions of those settings will appear
in the right column.
Click this button for a list of ESP
configuration settings that are
different than default settings.
Click Save As to save the
report as plain text or a
tab-delimited text file.
• To create a symbol containing any of the command settings in the table, click Generate
Barcode.
• To save the Differences from Default report, either as plain text or as a tab-delimited
text file, click Save As.
• Click Send and Save to send the settings to the imager and save them, or Send to
Reader to send the settings without saving them.
Important: To use Differences from Default, connect to the imager and Receive
Reader Settings via the Send/Recv button on the toolbar.
7-10
Click Generate Barcode to display the Bar Code
Dialog. Then create configuration symbols containing
the required configuration commands.
Send configuration settings to the
imager and save in ESP by clicking
Send and Save.
QX Hawk Industrial Imager User's Manual
Send configuration settings to
the imager without saving by
clicking Send to Reader.
