This section explains the basic structure and elements of ESP (Easy Setup Program).
When ESP is opened, unless otherwise specified in ESP Preferences, the EZ Mode view
will appear. App Mode contains several tree controls (Communication, Read Cycle,
Symbologies, I/O Parameters, Symbol Quality, Matchcode, and Diagnostics), a
Setup interface, a Terminal interface, and a Utilities interface.
ESP can be used to configure the QX Hawk in three different ways:
• Graphic User Interfaces: Imager settings can be configured using such point-and-click
tools as buttons, spin boxes, check boxes, and drag-and-drop functions.
• Tree Controls: Each tree control contains a list of all command settings that pertain to
that specific area of imager operation. Each parameter can be configured using dropdown
menus or fields where characters can be entered.
• Terminal: ESP's Terminal allows the user to send serial configuration and utility commands
directly to the imager by typing them in the provided field.
Information about using specific commands in ESP is provided in subsequent sections.
For ESP system requirements, see
QX Hawk Industrial Imager User's Manual

2 Using ESP

Minimum System Requirements in Chapter 1, Quick Start.
