Appendix B — Electrical Specifications
Power Requirement
QX Hawk Connectors
QX Hawk (Back View)
Output 2
New Master
Output 1
Output 3
Ground
Input Common
Output Common
A (Serial) M12 12-pin Plug
RS-422/485 RxD (–)
Input
Common
Ground
RS-422/485
RxD (+)
RS-422/485
TxD (+)
Input 1
RS-422/485 TxD (–)
B (Serial) M12 12-pin Socket
QX Hawk Industrial Imager User's Manual
9 Watts (max.), 10-28VDC, 200 mV p-p max. ripple, 270mA at
24VDC (typ.)
A is a serial M12 12-pin plug.
B is a serial M12 12-pin socket or an Ethernet M12
8-pin socket.
Default
Power
RS-232
TxD
Trigger
RS-232 RxD
RS-232 TxD/
RS-232 RTS
Trigger
RS-232 RxD/
RS-232 CTS
RX (+)
Power
Terminated
B (Ethernet) M12 8-pin Socket
Terminated
TX (+)
Terminated
RX (–)
Terminated
TX (–)
Terminated
Appendices
A-7
