Microscan QX Hawk User Manual page 329

Read Cycle
Trigger / Trigger Filter Duration
Serial Trigger Character
External Trigger State
End of Read Cycle
Decodes Before Output
Multisymbol
Serial Trigger Start Character
Serial Trigger Stop Character
Capture Mode
Capture Time
Store No Read Image
Image Processing Timeout
Number of Symbols in Field of View
Trigger Mode / Filter Duration
Trigger Mode
Serial Cmd: <K200,trigger
Default: 0 = Continuous Read
Options: 0 = Continuous Read
1 = Continuous Read 1 Output
2 = External Level
3 = External Edge
4 = Serial Data
5 = Serial Data and Edge
Leading Edge Trigger Filter
Serial Cmd: <K200,trigger
Default: 313
Options: 1 to 65535 (x 32.0 µs)
Trailing Edge Trigger Filter
Serial Cmd: <K200,trigger mode,leading edge trigger
Default: 313
Options: 1 to 65535 (x 32.0 µs)
Serial Trigger Character (Delimited)
Serial Cmd: <K201,serial trigger
Default: Space (0x20)
Options: Any 7-bit ASCII character
QX Hawk Industrial Imager User's Manual
<K200,trigger mode,leading edge trigger filter duration,trailing
edge trigger filter duration>
<K201,serial trigger character>
<K202,external trigger state>
<K220,mode,read cycle timeout>
<K221,number before output>
<K222,number of symbols,multisymbol separator>
<K229,start character>
<K230,stop character>
<K241,mode,number of captures,rapid capture mode>
<K242,time before first capture,time between 1-2,time between
2-3,time between 3-4,time between 4-5,time between 5-6,time
between 6-7,time between 7-8>
<K244,image storage type,image storage mode>
<K245,image processing timeout>
<K518,number of symbols in field of view>
mode,leading edge trigger filter,trailing edge trigger filter>
mode,leading edge trigger
(~10 ms)
(~10 ms)
character>
filter,trailing edge trigger filter>
filter,trailing edge trigger
Appendices
filter>
A-31
