Microscan MINI Hawk Xi Configuration Manual

MINI Hawk Xi
Configuration Guide
Hardware Required
Item Description
MINI Hawk Xi High Performance Imager
(C)ommunication: 1 (Ethernet)
1 (L)ens: 1 = Standard Density; 2 = High Density; 3 = Ultra High Density
(S)ensor: 0 = WVGA; 1 = SXGA
(O)ption: 0 = Standard; 1 = Custom
2 QX-1 Interface Device
3 Power Supply, M12 12-pin Socket, 1.3 m (Screw-On)
4 Photo Sensor, M12 4-pin Plug, NPN, Dark On, 2 m
5 Cordset, M12 12-Pin Socket (Screw-on) to Flying Leads, 3M
MINI Hawk Xi Configuration
Ethernet Standalone
1
3
Ethernet Standalone with Flying Leads
1
5
MINI Hawk Xi Pin Assignments
Output 2
Default
New Master
Output 1
Output 3
Ground
Host RxD
Input Common
Output Common
M12 12-pin Plug
QX-1 Interface
Device (Top View)
Connector T on the QX-1
P
Interface Device is the
trigger connector.
Connectors 1, 2, and 3
T
can be used to bus power
and data as required by
the application.
Copyright ©2015 Microscan Systems, Inc.
Ethernet Standalone with QX-1
Power
Host
TxD
Trigger
RJ45 Plug
Trigger
Ground
Trigger Connector (T) 4-pin Socket
1
2
3
4
8 NC
7 NC
6 RX (–)
5 NC
4 NC
3 RX (+)
2 TX (–)
1 TX (+)
+10-28V
Trigger/New Master / Input 1 Common
Part Number
FIS-6310-CLSOG
98-000103-02
97-000003-03
99-000020-02
61-000167-02
P/N 83-216310-04 Rev A
