Serial Commands
Appendix E — Serial Commands
Note: For a list of utility commands such as defaults, read rate requests, device control
options, and imager status requests, see
Communication
RS-232 A
RS-232 B
RS-422
Ethernet
Ethernet TCP Ports
Search and Configure Mode
RS-232 A Data Type
RS-232 B Data Type
RS-422 Data Type
Ethernet TCP Port 1 Data Type
Ethernet TCP Port 2 Data Type
Preamble
Postamble
Response Timeout
LRC Status
ACK/NAK Options
Polling Mode Options
Autoconfiguration Daisy Chain
Protocol Selection
External Data Routing
Array Communication Modes
Read Cycle
Trigger / Trigger Filter Duration
Serial Trigger Character
External Trigger State
End of Read Cycle
Decodes Before Output
Multisymbol
Serial Trigger Start Character
Serial Trigger Stop Character
Capture Mode
A-12
Serial Utility Commands
<K100,baud rate,parity,stop bits,data bits>
<K101,status,baud rate,parity,stop bits,data bits>
<K102,status,baud rate,parity,stop bits,data bits>
<K126,status,IP address,subnet,gateway,IP address mode>
<K127,TCP Port 1,TCP Port 2>
<K128,ESP Search and Configure Mode>
<K130,symbol data output,extra symbol information,diagnostic
output,external source processing mode>
<K131,symbol data output,extra symbol information,diagnostic
output,external source processing mode>
<K132,symbol data output,extra symbol information,diagnostic
output,external source processing mode>
<K133,symbol data output,extra symbol information,diagnostic
output,external source processing mode>
<K134,symbol data output,extra symbol information,diagnostic
output,external source processing mode>
<K141,status,preamble>
<K142,status,postamble>
<K143,response timeout>
<K145,status>
<K147,RES,REQ,STX,ETX,ACK,NAK>
<K148,RES,REQ,STX,ETX,ACK,NAK>
<K150DAISY>
<K160,protocol,address,protocol port>
<K161,mode,destination port,ambles to source,echo to
source,output at end of read cycle,output at ETX,output at timeout>
<K162,mode,source,daisy chain i.d. status,daisy chain i.d.>
<K200,trigger mode,leading edge trigger filter duration,trailing
edge trigger filter duration>
<K201,serial trigger character>
<K202,external trigger state>
<K220,mode,read cycle timeout>
<K221,number before output>
<K222,number of symbols,multisymbol separator>
<K229,start character>
<K230,stop character>
<K241,mode,number of captures,rapid capture mode>
QX Hawk Industrial Imager User's Manual
on page A-64.
