Lens Model
This value must reflect the correct camera lens currently installed on the product. This
value is properly configured after leaving factory. However, since the lens can be changed
by the user, this parameter needs to be updated to reflect the currently installed lens.
To verify lens type, turn off power to the QX Hawk (do not look into the targeting laser).
Then look at the outer rim of the unit's camera lens. The following markings define the
correct "Lens Type" parameter value:
'.', and "15"
'..', and "30"
'...', and "45"
When a lens is changed on the QX Hawk, the user can optimize the accuracy of the Focal
Distance parameter by using the
This parameter is "sticky". Once saved with a
"defaulted" with
<Zrdall>
QX Hawk Industrial Imager User's Manual
= Lens Type 1
= Lens Type 2
= Lens Type 3
<@OPTIC>
or <K525d>.
command.
<Z>
or
<Zc>
command, it can only be
Setup
4-7
