Sq1 Dynamics Effect - Midas PRO2 Owner's Manual

138
Item
15
16
Feedback
The pitch shifter accepts the input signal and then delays it and plays it back at a
different speed, so that its output is delayed and pitch shifted. When this output is fed
back into the pitch shifter, further delays and more pitch shifting occur. This can lead
to some strange effects, such as feedback.

SQ1 Dynamics effect

For information on the Klark Teknik Square One Dynamics, refer to its Operator Manual
(part number DOC02-SQ1DYNAMIC).
Front panel of the SQ1 dynamics effect
Control
ON switch
Win Sz control
knob
Chapter 16: Internal Effects
Function
Switches pitch shifter effect on/off.
Sets the window size used by the pitch shift
algorithm. High values result in larger latency, but
better quality for low frequency or polyphonic audio
source. Low values produce low latency and work
best on monophonic audio source.
PRO2 Live Audio System
Owner's Manual
