Midas PRO2 Owner's Manual page 242

224
Monitor Mix (Low Latency)
The following table shows the delay compensation settings for this mix.
Option
Master to Matrix Post-processing
Input Channels
Insert
Aux Sends
Monitor Mode (Align with Masters)
Insert
Send-FX-Return
Graphic EQ
Master and Matrix
Insert
Graphic EQ
Input Ch Insert (OFF)
Aux Insert (OFF)
Aux Send & Return (OFF)
Aux GEQ (OFF)
Masters / Matrix Insert (OFF)
Masters / Matrix GEQ (OFF)
Master to Matrix tap-off = pre-processing.
Aux alignment (OFF)
The following example signal paths all measure the same latency of 172 samples @
96kHz = 1.79 ms:
• FOH XLR – IP – MAST – XLR
• XLR – IP – MAST – XLR
• XLR – IP – MTX – XLR
• XLR – IP – MAST- MTX – XLR
• XLR – IP – AS – XLR
• XLR – AS DI – AS – XLR
• XLR – AR (Input) – MAST – XLR
• XLR – AR (Input) – MAST - MTX - XLR
Chapter 28: Delay Compensation (Latency)
On/off status
Off
Off
On
Off
Off
Off
Off
Off
PRO2 Live Audio System
Owner's Manual
