Midas PRO2 Owner's Manual page 280

262
Item
3
4
5
6
For more details, refer to "Stereo panning" on page 86 and "Spatial imaging system
(SIS™)" on page 313.
Description
pan control knob, adjusts the relative levels sent to a left-right bus pair or
the master left-centre-right (LCR) buses. In SIS™ mode, it can also control
the 'image' to give a constant power crossfade from LCR to stereo.
MON (mono) switch, connects post-fader channel signal to mono master
bus.
mono level/SIS image dual-function control knob. In mono mode, it acts
as a mono level control knob to adjust the mono signal level. In SIS™
mode, it becomes a SIS image control knob that modifies pan control knob
operation to place the channel within a three-speaker system (see "Stereo
panning" on page 97).
Quick access button, selects the master detail area on the GUI channels
strip.
Chapter 30: Input Channels
PRO2 Live Audio System
Owner's Manual
