Midas PRO2 Owner's Manual page 149

Delay effect
Item
13
14
15
16
17
18
19
20
PRO2 Live Audio System
Owner's Manual
Control
Model select
button
ON switch
Gain control knob
Mix control knob
HF Depth control
knob
Right channel
delay time control
knob
Tempo control
knob
Tap button
Function
Selects digital or analogue delay model. Current
selection is shown by the illumination of one of the
LEDs above (Dig. or Anlg.).
Switches the delay effect on/off.
Adjusts the amount of gain between -20 and +20,
with 0 at top dead centre.
Adjusts the mix between dry (0%) wet (100%).
Adjusts depth of HF damping modulation. Range is 0
to 100, with 50 at top dead centre.
For entering the desired delay time (in ms).
Adjusts the tempo in tempo mode. Range is from 60
to 240 beats per minute (bpm).
For manually tapping the tempo once the unit is in
BPM Sync (TAP TEMPO) mode.
131
