Midas PRO2 Owner's Manual page 69

About the Patching screen
Busses tab — From
The Busses tab allows routing from the
auxes, matrices and master outputs.
This tab can also be accessed directly via
the dest button in the mixes section of the
input channels and in the direct input
section of the output channels (see "Direct
input controls" on page 304).
Dir. Out (Direct Out) tab — From
The Dir. Out (Direct Out) tab allows you to
patch any of the 96 input channels internally.
For example, to an effect or to provide a way
out of the DL251/DL252 Audio System I/O
via a line I/O unit.
This tab can also be accessed directly via the
dest button in the direct output section of
the input channels.
PRO2 Live Audio System
Owner's Manual
51
