EQ
This section shows the parameters of the EQ section affected by stereo linking.
Item
1
2
3
4
5
6
7*
8
* Not shown in diagram.
Note: Although bands 5 and 6 are not shown above, the items in the table also apply.
Both bands have items 2, 3 and 4, band 6 also has item 7.
Appendix J: Parameters Affected By Stereo Linking
4 5/6/7
1
3
Control
EQ switch
gain control knob
width control knob
freq. control knob
SHAPE switch
SHAPE switch
SHAPE switch
GEQ
1
2
Parameter
EQ on/off
EQ gain level
EQ width
EQ frequency
Band 1 shelving mode: bell, warm, high pass 6dB
or high pass 12dB
Band 2 shelving mode: bell or high pass 24dB
Band 6 shelving mode: bell, soft, low pass 6dB or
low pass 12dB
All GEQ parameters. (GEQ parameters linked
when both linked channels have a GEQ assigned to
them.)
8
4
2
3
4
2
3
4
6
2
3
4
5
2
3
