Miscellaneous digital characteristics
Type I/O
Word clock IN
Word clock OUT
AES sync IN
AES sync OUT

Main processing functions

Main input channel functions
Input channel hi pass
Input channel lo pass
Input channel treble
Input channel hi mid
Input channel lo mid
Input channel bass
Appendix C: Technical Specification
Description Notes
Accepts TTL level, 96kHz square wave;
impedance 75 ohms
Provides TTL level, 96kHz square wave
Accepts a 96kHz digital audio signal
conforming to AES3-2003
Provides a 96kHz grade II reference
signal conforming to AES3-2003
10Hz to 400Hz swept in digital domain
Slope selectable 12dB/Oct or 24dB/Oct
2kHz to 20kHz swept in digital domain
Slope selectable 6dB/Oct or 12dB/Oct
Parametric Operation
Frequency 1kHz to 25kHz swept
Gain +16dB to –16dB
BW 0.1 Oct to 3 Oct
Shelf Operation
Frequency 1kHz to 25kHz swept
Gain +16dB to –16dB
Soft, Classic or Bright (minimum harmonic disruption) curves
Parametric Operation
Frequency 320Hz to 8kHz swept
Gain +16dB to –16dB
BW 0.1 Oct to 3 Oct
Parametric Operation
Frequency 80Hz to 2kHz swept
Gain +16dB to –16dB
BW 0.1 Oct to 3 Oct
Parametric Operation
Frequency 16Hz to 400Hz swept
Gain +16dB to –16dB
BW 0.1 Oct to 3 Oct
Shelf Operation
Frequency 16Hz to 400Hz swept
Gain +16dB to –16dB
Warm, Classic or Deep (minimum harmonic disruption) curves
Connector
BNC
BNC
XLR
XLR
